Loop type Cut to Length Line with Auto Drop type Stacker

Loop type CTL with Auto Drop type Stacker advanced metal processing system designed to uncoil, level, measure, cut, & automatically stack flat metal sheets at high speed & with high accuracy. Loop system allows continuous operation of the leveller while the cutting & stacking sections work independently, improving productivity, line stability, & sheet quality. Auto drop type stacker ensures accurate, scratch-free & organized sheet stacking with minimal manual intervention. This type of CTL line usually used in steel service centers, construction, appliance, automotive, & electrical industries. Loop type CTL line, loop pit or loop tower is installed between the levelling section & the cutting section. Leveller runs continuously The shear operates in start-stop or flying mode, This design ensures smooth material flow, even at high speeds or during cutting interruptions, The loop absorbs speed differences, preventing strip tension issues, Auto drop type stacker automatically, Receives cut sheets from the shear, Lowers (drops) each sheet precisely onto a stacking table, Maintains correct sheet alignment & stack height, Main Components, Entry Pinch Rolls & Leveller, Control & Automation System, Measuring & Feeding Unit, Loop Pit or Loop Tower, Cutting Unit, Auto Drop type Stacker, Decoiler or Un-coiler, Working Principle Shear cuts sheets to programmed length, Strip passes through pinch rolls & leveller for flattening, Coil is loaded onto the de-coiler, The leveled strip enters the loop pit, forming a controlled loop, Strip feeds into the measuring system, Sheets are transferred to the auto drop stacker, which gently drops each sheet onto the stack, Applications Appliance Manufacturing - Panels & housings, Electrical Industry - Panel boards and enclosures, Steel Service Center - Flat sheet production, Furniture Industry - Flat metal components, Construction - Roofing and cladding sheets, Automobile - Body panels, blanks,
