Combination Line in Cut to Length Line Mode Slitting Machine
Combination Line in CTL Mode with Slitting Machine an advanced & flexible metal processing system that integrates slitting & cut to length operations into a single production line. Combination line allows manufacturers to Slit wide coils into narrow strips & Cut sheets or strips to precise lengths in the same line or in separate operational modes. The system is ideal for manufacturers who need both narrow strips and flat sheets from the same coil material, offering high productivity, space savings, and reduced investment cost. Main Components Decoiler or Uncoiler Entry Pinch Rolls & Leveller Loop Pit or Accumulator Slitting Section (Slitting Mode) Strip Diverter or Transfer System Cut to Length Section (CTL Mode) Control & Automation System Working Principle Slitting Mode Coil is decoiled and leveled. Strip enters slitting head where it is cut into multiple narrow strips. Slit strips are separated and tensioned. Strips are rewound or transferred for further processing. CTL Mode Coil is decoiled and leveled. Material bypasses slitting knives. Strip enters measuring system. Shear cuts sheets to programmed length. Sheets are stacked automatically. Industries Electrical Industry - Transformer strips, panel sheets Automotive - Narrow strips and flat blanks Appliance Manufacturing - Panels & strip components Solar Industry - Mounting rails & brackets Furniture Industry - Frames & narrow sheet parts Steel Service Centers - Custom slit coils & sheets Advantages High precision in both width & length Lower manpower & maintenance cost One line for slitting & sheet cutting Flexible production planning Quick changeover between modes Reduced floor space & equipment cost Combination Line in Cut to Length CTL Mode with Slitting Machine versatile & cost-effective solution for modern metal processing facilities.
Description
Combination Line in CTL Mode with Slitting Machine an advanced & flexible metal processing system that integrates slitting & cut to length operations into a single production line.
Combination line allows manufacturers to
Slit wide coils into narrow strips &
Cut sheets or strips to precise lengths in the same line or in separate operational modes.
The system is ideal for manufacturers who need both narrow strips and flat sheets from the same coil material, offering high productivity, space savings, and reduced investment cost.
Main Components
Decoiler or Uncoiler
Entry Pinch Rolls & Leveller
Loop Pit or Accumulator
Slitting Section (Slitting Mode)
Strip Diverter or Transfer System
Cut to Length Section (CTL Mode)
Control & Automation System
Working Principle
Slitting Mode
Coil is decoiled and leveled.
Strip enters slitting head where it is cut into multiple narrow strips.
Slit strips are separated and tensioned.
Strips are rewound or transferred for further processing.
CTL Mode
Coil is decoiled and leveled.
Material bypasses slitting knives.
Strip enters measuring system.
Shear cuts sheets to programmed length.
Sheets are stacked automatically.
Industries
Electrical Industry - Transformer strips, panel sheets
Automotive - Narrow strips and flat blanks
Appliance Manufacturing - Panels & strip components
Solar Industry - Mounting rails & brackets
Furniture Industry - Frames & narrow sheet parts
Steel Service Centers - Custom slit coils & sheets
Advantages
High precision in both width & length
Lower manpower & maintenance cost
One line for slitting & sheet cutting
Flexible production planning
Quick changeover between modes
Reduced floor space & equipment cost
Combination Line in Cut to Length CTL Mode with Slitting Machine versatile & cost-effective solution for modern metal processing facilities.
| HSN Code | 84624900 |
| GST Rate | 18% |
| Min Order Quantity | 1 kilogram |
| Product Color | ["#000000","#0000FF","#FFFFFF","#C0C0C0"] |
| Product Unit | kilogram |
| HSN/SAC Code | 84624900 |
