High Speed Rotary Oscillating Fly Shear Cut to Length Machine

High-Speed Rotary Oscillating Fly Shear CTL Machine advanced metal processing system designed to cut continuously moving metal strip or sheet into precise lengths at very high line speeds using rotary oscillating fly shear mechanism. Machine widely used where tight length tolerance, high productivity, & clean cutting are required without stopping or slowing the strip. Rotary oscillating fly shear combines the advantages of rotary shearing & fly cutting. Shear unit accelerates, synchronizes with the strip speed, executes the cut while moving with the strip, & then decelerates back to its start position. This allows continuous strip movement, minimal tension difference, & extremely high cutting speed. Characteristics Continuous on-the-fly cutting High-speed operation with precise length control Smooth, low-vibration cutting Suitable for thin to medium gauge materials Clean, burr-free cut edges Main Components Decoiler or Un-coiler Run Out Table or Conveyor Loop Pit or Strip Accumulator Length Measuring System Rotary Oscillating Fly Shear Unit Automatic Stacker Electrical & Control System Pinch Roll & Leveller or Straightener Working Principle Coil uncoiled & passed through the leveller for flatness Strip enters loop pit or accumulator to ensure continuous flow Rotary blades cut the strip while moving with it Shear head then oscillates back to its initial position Encoder measures strip length in real time Fly shear carriage accelerates to match strip speed Cut sheets are conveyed & stacked automatically Types Rotary Oscillating Fly Shear Crank-type Fly Shear (Alternative) Applications Electrical Industry - Panel blanks and enclosures Appliance Manufacturing - Panels & casings Construction - Roofing and cladding sheets Metal Service Centers - High-speed sheet processing HVAC - Duct & panel blanks Automotive - Body panels, blanks for stamping
