Servo Feeder Terminal Equipment's
Servo Feeder precision feeding system used in metal processing & press operations to feed material (sheet, coil or strip) accurately & consistently into machines such as presses, punching units, & roll forming lines. It uses a servo motor-driven mechanism for high accuracy, repeatability, & speed control. Main Functions Feed material with high accuracy & consistency Synchronize feeding with press or punching operations Control feed length, speed, & positioning Improve production efficiency & reduce material wastage Working Principle Feed length programmed in the control system Servo system ensures precise movement & stopping position Material (coil/strip) passes through feed rollers Servo motor drives the rollers via gearbox or direct drive Feeding synchronized with the press or punching cycle Types of Servo Feeders Zig-Zag Roll type Gripper type High-Speed Key Components Servo Motor - Provides precise motion control Feed Rollers - Grip and move the material Frame Structure - Rigid body for stability Drive System - Gearbox, belts, or direct coupling Control System - PLC or CNC controller with HMI Encoder - Feedback device for accurate positioning Straightener (Optional) - Removes coil set before feeding Applications Automotive component manufacturing Roll forming machines Power press lines Electrical and appliance industries Rotary punching units Sheet metal stamping Advantages Reduced material wastage Easy programming & adjustment Suitable for automation & integration Increased production speed High precision and repeatability Safety Features Overload protection Safety guards Emergency stop system Interlock with press machine Servo Roll feeders are used to feed coil stock to pressing, punching, piercing, embossing or stamping operations.
Description
Servo Feeder precision feeding system used in metal processing & press operations to feed material (sheet, coil or strip) accurately & consistently into machines such as presses, punching units, & roll forming lines. It uses a servo motor-driven mechanism for high accuracy, repeatability, & speed control.
Main Functions
Feed material with high accuracy & consistency
Synchronize feeding with press or punching operations
Control feed length, speed, & positioning
Improve production efficiency & reduce material wastage
Working Principle
Feed length programmed in the control system
Servo system ensures precise movement & stopping position
Material (coil/strip) passes through feed rollers
Servo motor drives the rollers via gearbox or direct drive
Feeding synchronized with the press or punching cycle
Types of Servo Feeders
Zig-Zag
Roll type
Gripper type
High-Speed
Key Components
Servo Motor - Provides precise motion control
Feed Rollers - Grip and move the material
Frame Structure - Rigid body for stability
Drive System - Gearbox, belts, or direct coupling
Control System - PLC or CNC controller with HMI
Encoder - Feedback device for accurate positioning
Straightener (Optional) - Removes coil set before feeding
Applications
Automotive component manufacturing
Roll forming machines
Power press lines
Electrical and appliance industries
Rotary punching units
Sheet metal stamping
Advantages
Reduced material wastage
Easy programming & adjustment
Suitable for automation & integration
Increased production speed
High precision and repeatability
Safety Features
Overload protection
Safety guards
Emergency stop system
Interlock with press machine
Servo Roll feeders are used to feed coil stock to pressing, punching, piercing, embossing or stamping operations.
| HSN Code | 84624990 |
| GST Rate | 18% |
| Min Order Quantity | 1 kilogram |
| Product Color | ["#000000","#0000FF","#FFFFFF","#FFFF00","#800000","#C0C0C0"] |
| Product Unit | kilogram |
| HSN/SAC Code | 84624990 |
