Description

D Model Conveyor 20 feet Bag stacker (Single stage)
Single Side Height Adjustment
Conveyor Length Total 20 ft
Maximum Height 14.5 ft
Minimum Height 4 ft
Conveyor Width 760 mm, Belt Width 600 mm
Belt 3 Ply 5.5 mm Chevron Green V Belt
Belt Speed 16 Mtr / Minute
Drive Roller Dia 155 mm Rubber Mould 15 mm Thicknes
Driven Roller Dia 139 mm - Make Macro
Return Roller Dia 48 mm - Make Macro
Guide Roller 42 mm with Double Bearing SKF
Gear Box Tw 75
Bearing Block Skf Casting
Conveyor Sheet Thickness 3 mm Laser Processed
Frame & Leg Support 80 x 40 x 3 mm
Conveyor Sheet Bottom Support 80 x 40 x 3 mm
Hydraulic Power Pack Macro Make
Hydraulic Cylinder Dia 80x750 mmpiston thick 53 mm
Twin Cylinder Both Side
Surface Finish Auto Coat Paint,Doublecoated Rubilex
Panel Box Inside Frame
Rubber Moulded Wheel - Tyre
Paint Clear Extra Coat
1 Hp Motor for Hydraulic
2 Hp Motor for Belt
