Flying Die High Speed Shear or on the Fly Cutting Shear Cut to Length Machine
Flying Die High-Speed Shear, also known as an on the-Fly Cutting Shear Cut to Length CTL Line, advanced metal cutting system designed to cut non-stop moving metal strip into precise lengths without stopping or slowing the line. This technology is widely used in high-speed CTL lines where maximum productivity, high accuracy, & smooth strip handling critical. Flying die on-the-fly shear CTL machine, the shear unit is mounted on a moving carriage that accelerates to match the strip speed, performs the cut while traveling with the strip, & then returns to its start position. Key Characteristics Continuous on-the-fly cutting Extremely high production speed Excellent cut accuracy and repeatability Low strip stress and vibration Ideal for thin to medium gauge materials Main Components Decoiler or Un-coiler Pinch Rolls & Leveller Loop Pit or Strip Accumulator Length Measuring System Flying Die High-Speed Shear Unit Run-Out Table or Conveyor Automatic Stacker Electrical & Control System Working Principles Target length reached, flying shear carriage accelerates to strip speed The shear cuts the strip while moving with it Encoder measures the exact strip length continuously The coil uncoiled & levelled Strip passes through loop pit for tension control After cutting, the carriage returns to start position
Description
Flying Die High-Speed Shear, also known as an on the-Fly Cutting Shear Cut to Length CTL Line, advanced metal cutting system designed to cut non-stop moving metal strip into precise lengths without stopping or slowing the line. This technology is widely used in high-speed CTL lines where maximum productivity, high accuracy, & smooth strip handling critical.
Flying die on-the-fly shear CTL machine, the shear unit is mounted on a moving carriage that accelerates to match the strip speed, performs the cut while traveling with the strip, & then returns to its start position.
Key Characteristics
Continuous on-the-fly cutting
Extremely high production speed
Excellent cut accuracy and repeatability
Low strip stress and vibration
Ideal for thin to medium gauge materials
Main Components
Decoiler or Un-coiler
Pinch Rolls & Leveller
Loop Pit or Strip Accumulator
Length Measuring System
Flying Die High-Speed Shear Unit
Run-Out Table or Conveyor
Automatic Stacker
Electrical & Control System
Working Principles
Target length reached, flying shear carriage accelerates to strip speed
The shear cuts the strip while moving with it
Encoder measures the exact strip length continuously
The coil uncoiled & levelled
Strip passes through loop pit for tension control
After cutting, the carriage returns to start position
| HSN Code | 84624900 |
| GST Rate | 18% |
| Min Order Quantity | 1 kilogram |
| Product Color | ["#000000","#FFFFFF","#FFFF00","#C0C0C0"] |
| Product Unit | kilogram |
| HSN/SAC Code | 84624900 |
