Fixed Mechanical High-Speed Shear Cut to Length Machine

Fixed Mechanical High-Speed Shear CTL Machine a robust & cost-effective metal processing machine designed to cut continuously fed metal strip into precise lengths using fixed-position mechanical (crank-type) shear. CTL machine widely used where high production speed, consistent operation, & simple mechanical design required - particularly for thin to medium gauge materials. Fixed mechanical shear CTL machine, the shear unit is mounted at fixed location & operates using mechanical crank, cam, or eccentric drive powered by motor & flywheel. The strip moves nonstop or semi-continuously, & shear cuts at high strokes per minute without complex servo or hydraulic systems. Key Characteristics Fixed-position mechanical shear High-speed cutting for repetitive lengths Simple, durable mechanical design High strokes per minute (SPM) Low maintenance & operating cost Main Components Decoiler or Un-coiler Pinch Roll & Straightener Measuring System Fixed Mechanical High-Speed Shear Run-Out Table or Conveyor Electrical Control System Working Principle Coil is uncoiled & fed through the straightener Strip moves continuously toward the shear Length measuring system tracks the strip When the preset length is reached, the mechanical shear performs high-speed stroke The strip may slow slightly or momentarily pause, depending on speed and thickness Cut sheets move to the run-out table and stacker Types Crank-type Shear Cam-Driven Shear Eccentric-type Shear Applications Automotive Components - Blanks and reinforcements Appliance Manufacturing - Panels and casings Electrical Industry - Enclosures & panels Metal Furniture - Panel blanks General Fabrication - Standard-length sheets Roofing & Cladding - Sheet preparation
