Description

Combination Slitting Line a multipurpose metal processing system designed to perform two operations in one integrated production line.

Coil Slitting - cutting wide metal coils into thin strips.
Cut to Length (Blanking) - cutting metal sheets into specific lengths.

Line generally used by steel service centers, metal processing industries, & manufacturing plants that need both slit coils & flat sheets from the same raw material coil.

Advantage of a combination line flexibility & cost efficiency, allowing operators to switch between slitting mode & cut to length mode based on production requirements.

Purpose
Process metal coils into many narrow strips.
Improve production efficiency & plant space utilization
Provide flexible manufacturing for different industries.
Produce precise sheet blanks directly from coils.
Reduce the need for separate slitting & cut-to-length lines

Main Components
De-coiler (Un-coiler)
Entry Guide & Pinch Roll
Slitting Unit
Scrap Winder
Loop Pit or Accumulator
Leveller (Flattening Unit)
Shearing Unit (Cut-to-Length)
Stacker System
Re-coiler
Electrical Control System

Working Process -
Metal coil loaded onto the de-coiler.
Strip is guided into the slitting section .
Slitting knives cut the coil into narrow strips
Depending on the selected mode:

Slitting Mode
Strips pass through separator & tension unit
Slit coils are recoiled

Cut-to-Length Mode
Strip passes through leveller
Shear cuts sheets to required lengths
Sheets are stacked automatically

Applications
Automotive - Body parts & structural sheets
Construction - Roofing sheets & panels
Electrical - Panel boards & cabinets
Furniture - Metal furniture components
Appliance - Refrigerator & washing machine panels
Steel Service Centers - Custom sheet & strip supply

Advantages
Multi-purpose production capability
Reduced equipment investment
Saves factory space
High production flexibility
Lower operating cost
Fast changeover between processes
