Combination Line for CTL Mode Roll Forming Machine

Combination Line for CTL Mode & RFM a multi-functional metal processing system designed to operate in two production modes using a single decoiler & common front-end equipment. Cut to Length CTL Mode - Produces flat sheets or plates of precise lengths. Roll Forming Mode - Produces continuous or cut profiles such as channels, sections, & structural shapes. This dual-purpose line provides maximum flexibility, space efficiency, & cost savings, making it ideal for manufacturers handling both sheet cutting & profile forming from the same coil stock. Combination line: The coil processing section (uncoiler, leveller, feeder) shared. A diverter or transfer system directs the material either to: CTL cutting section, or roll forming mill. Main Components Decoiler / Uncoiler Entry Pinch Rolls & Leveller Loop Pit / Accumulator Material Diverter System Cut to Length Section (CTL Mode) Roll Forming Section (Roll Forming Mode) Control & Automation System Working Principle CTL Mode Operation Roll Forming Mode Operation Industries Using Combination Lines Automotive Components - Panels and roll-formed parts Solar Industry - Mounting structures and flat panels Pre-Engineered Buildings - Panels and framing sections Storage & Racking - Uprights, beams, flat sheets Construction & Infrastructure - Sheets and structural profiles Electrical Industry - Enclosures and support frames Advantages Faster ROI & improved flexibility Efficient floor space utilization Quick changeover between modes Shared manpower and utilities One machine for two production processes Reduced capital investment Ideal for manufacturers handling multiple product types Reduces machine idle time Enhances production planning flexibility Minimizes operating and maintenance costs
